Metal Insulated Panel

Product Description

Built with exceptional strength and thermal performance, yet incredibly lightweight, our steel panels can reduce the need for supporting steelwork in high-performing technical environments.

Whether you’re building freezer rooms, cold storage, data centres, a pharmaceutical clean room, medical environment or reinventing agriculture with a vertical farm, our steel insulated panels can match your requirements.

Clean Environment Panels
Insulated panels for Clean Rooms, Medical and Pharmaceutical controlled environments.

• A solution for demanding spans up to 15m, where honeycomb systems are length-restricted.
• Superior smooth surface finish with no unsightly joints, so your environment remains easy to maintain and clean.
• Cover width of 1155mm to optimise delivery and install costs.
• Gives excellent thermal insulation and is a zero ozone depletion potential product.

Controlled Environment Panels
This cost-effective, internal food-safe insulated panel with steel facings is ideal for refurbishment projects.

• The thinnest insulated panels in our Control range, available in 50mm and 80mm thicknesses.
• Cover width of 1155mm to optimise delivery and install costs.
• There are no unsightly joins and you don’t need supporting frames, producing a clean and tidy finish.
• Control in the 50mm thickness is perfectly suited for use as a ‘liner’ panel to replace PVC single skin.

Control 30 Panels
For fire-safe general food production, Control 30 is an internal insulated panel with steel facings, and provides fire performance for both integrity and insulation.

• Ideal for ambient, chilled or freezer areas where non-intensive cleaning is required.
• Recommended for all temperature ranges between -40 to +50 °C.
• Provides 30 minutes of fire resistance and LPCB certified to LPS1208.
• Long cover width of 1155mm helps reduce your panel quantity requirements.

Control 60 Panels
Hemsec Control 60 insulated panels set the standard for combining safety, efficiency, and durability in temperature-controlled, fire-rated environments.

• Ideal solution for severe negative temperatures, with a superior thermal performance of 0.1W/Mk
• 60-minute fire resistance, LPCB certified to LPS1208, for both integrity and insulation.
• Copes with demanding spans within non-intensive cleaning environments and are ideal for firewall construction.
• A cover width of 1155mm helps reduce your panel quantity requirements.
