Flex STM (Steam Trap Monitoring)
Manufactured by DCO Systems Limited
Product Buying Options
Product Description
Our Flex STM model provides a flexible platform for monitoring offering sensor flexibility to meet your requirements. With dual temperature sensors included by default, the unit can be extended to up to 8 temperatures probes, and supports the full range of communications, storage, and sensing options from our options range. The IP66 enclosure is suitable for long-term outdoor installation.
Flexible configuration:
- 2x Clip-on Temperature Probes (-20°C to 300°C) included, with support for up to 8 probes.
Predictive maintenance:
- Real time alerts, from DiscoverRA platform or your reporting tools.
Flexible data:
- Out of the box support for the DiscoverRA cloud platform or integrate with your platforms.
Flexible reporting:
- Smart reporting intervals and up to 20 updates per hour.
Mounting sizes:
- Options for DN15 to DN300 pipes.
Smart device:
- Extended data analysis and smart data provided on-device.
Operational temperature:
- Environment: -40°C to 85°C
Enclosure type:
- IP66 enclosure, measuring 130mm x 91mm x 63mm.
To learn more about our steam trap monitoring range, please contact us or email info@dcosystems.co.uk.
