Flexible machining with the STAR SB-12
Techno Group are proud to utilise some of the most advanced machining equipment on the market. The STAR SB-12 is a highly versatile sliding head lathe in a small workshop footprint. It is the ideal choice for mass machining small components, that combines cost-effectiveness with consistent quality production.
Reducing lead-times with diverse machining capabilities
The main spindle is equipped with six turning tools and two fixed high-speed ER11 spindles for cross working. Additionally, there are three modular cross power-driven stations that can accept a range of cartridge attachments. This comprehensive tooling setup ensures that we have the flexibility to handle diverse machining tasks in the most effective way possible and reducing lead times for our customers.
Not only does the SB-12R Type G offer an array of tools, but it also provides the flexibility to switch between guide bush mode (Swiss type) and non-guide bush mode. This feature allows you to select the most suitable mode for specific machining requirements, further enhancing the machine’s adaptability and making it suitable for even more workloads.
Key Specifications
The highly equipped SB-12 comes with some impressive specs:
Standard machining diameter: 12mm (13mm optional)
Maximum Z1 stroke of 205mm in Swiss mode (Guide Bush)
Switchable between guide bush and non-guide bush modes
Main spindle speed: 15,000 rpm, sub-spindle speed: 12,000 rpm
C-axis control on main and sub-spindles
Up to 7 power tools on the main spindle
4 back-working power tools available
3 modular (cartridge) stations on the main platen
With all of this, its no wonder the SB-12 is one of the most relied on pieces of equipment in the Techno Group factory.
A compact powerhouse
Despite its small footprint, The SB-12 doesn’t compromise on power. The main spindle operates at up to 3.7kW, for extremely precise machining. The machine can also handle pieces up to 205mm in length and up to 12mm in diameter, meaning a huge range of small, bespoke components can be brought to life with the SB-12.
Try Techno Group for your next precision project
Techno Group are always pushing the boundaries by investing in new technology to further improve our offerings. Read more about some of our other machining capabilities on our blog.
To learn what the Star SB-12 could bring to your supply chain, get in touch with us using the form below to find out more. Follow us on LinkedIn for the latest updates from Techno Group.
